Description
Product information
| Weight | 46 lbs |
|---|---|
| Dimensions | 24 × 11 × 9 in |
| Product Line |
PowerOval |
| Quantity |
Each |
| Color |
Natural |
| Finish |
Natural |
| Material |
Aluminum |
| Valve Seal Material |
Viton |
| Valve Seal Style |
Positive Stop |
| Assembled/Bare |
Assembled |
| Chamber Volume |
113 cc |
| Plug Angle |
Angle |
| Intake Runner Volume |
280 cc |
| Exhaust Runner Volume |
129 cc |
| Intake Port Shape |
Oval |
| Intake Port Location |
Stock |
| Exhaust Port Shape |
D |
| Exhaust Port Location |
Raised |
| Intake Valve Size |
2.190 in |
| Intake Valve Included |
Yes |
| Intake Valve Material |
Stainless |
| Exhaust Valve Size |
1.880 in |
| Exhaust Valve Included |
Yes |
| Exhaust Valve Material |
Stainless |
| Valve Spring Included |
Yes |
| Intended Camshaft Style |
Hydraulic Roller |
| Maximum Lift |
0.700 in |
| Valve Spring Diameter |
1.550 in |
| Valve Spring Number |
Dual |
| Valve Spring Damper |
Yes |
| Valve Spring Retainers Included |
Yes |
| Valve Spring Retainer Material |
Chromoly |
| Valve Seal Included |
Yes |
| Pushrod Guide Plate Included |
Yes |
| Guide Plate Pushrod Size |
3/8 in |
| Valve Guide Included |
Yes |
| Valve Guide Material |
Bronze |
| Perimeter Mount Valve Cover |
Yes |
| Valve Seat Included |
Yes |
| Intake Valve Seat Material |
Ductile Iron |
| Exhaust Valve Seat Material |
Ductile Iron |
| Valve Seat Finish |
Machined |
| Combustion Chamber Finish |
As Cast |
| Intake Runner Finish |
As Cast |
| Exhaust Runner Finish |
As Cast |
| Intake Valve Angle |
24 Degree |
| Exhaust Valve Angle |
15 Degree |
| Accessory Bolt Holes |
Drilled and Tapped |
| Exhaust Port Raised Distance |
0.300 in |
| Brand |
TRICK FLOW |
| Condition |
New |
| Type |
Cylinder Heads |
| Manufacturer Part Number |
TFS-41310001-M13 |
Description Cylinder Head – PowerOval – Assembled – 2.190 / 1.880 in Valves – 280 cc Intake – 113 cc Chamber – 1.550 in Springs – Aluminum – Big Block Chevy – Each Features
