Description
Product information
| Weight | 8.82 lbs |
|---|---|
| Dimensions | 24.45 × 2.95 × 2.75 in |
| Product Line |
Oval Track-Xtreme |
| Camshaft Lifter Style |
Mechanical Flat Tappet |
| Advertised Intake Duration |
282.0 |
| Intake Duration At 0.050 In |
252.0 |
| Advertised Exhaust Duration |
292.0 |
| Exhaust Duration At 0.050 In |
258.0 |
| Intake Lift |
0.540 in |
| Exhaust Lift |
0.537 in |
| Lobe Separation Angle |
106 Degrees |
| Operating Range Rpm Lower |
3000 RPM |
| Operating Range Rpm Upper |
6700 RPM |
| Manufacturer Grind Number |
282XOS |
| Material |
Cast Iron |
| Color |
Natural |
| Finish |
Natural |
| Quantity |
Each |
| Note |
Mechanical Flat Tappet – Xtreme Oval: 1/4-3/8 tight. 327-358c.i., 12:1+ compression. 4 BBL with good intake and exhaust. |
| Hot Intake Lash |
0.016 |
| Hot Exhaust Lash |
0.018 |
| UPC Code |
36584015680 |
| Brand |
COMP CAMS |
| Type |
Camshafts |
| Condition |
New |
| Manufacturer Part Number (MPN) |
12-656-5 |
Description Camshaft – Xtreme Oval – Mechanical Flat Tappet – Lift 0.540 / 0.537 in – Duration 282 / 292 – 106 LSA – 3000 / 6700 RPM – Small Block Chevy – Each Features
