Description
Product information
| Weight | 8.84 lbs |
|---|---|
| Dimensions | 24.6 × 3 × 2.85 in |
| Product Line |
Oval Track |
| Camshaft Lifter Style |
Mechanical Roller Tappet |
| Advertised Intake Duration |
296.0 |
| Intake Duration At 0.050 In |
260.0 |
| Advertised Exhaust Duration |
304.0 |
| Exhaust Duration At 0.050 In |
266.0 |
| Intake Lift |
0.630 in |
| Exhaust Lift |
0.630 in |
| Lobe Separation Angle |
104 Degrees |
| Operating Range Rpm Lower |
4200 RPM |
| Operating Range Rpm Upper |
7000 RPM |
| Hot Intake Lash |
0.02 |
| Hot Exhaust Lash |
0.022 |
| Manufacturer Grind Number |
296BR-4 |
| Material |
Billet Steel |
| Color |
Natural |
| Finish |
Natural |
| Quantity |
Each |
| Note |
Mechanical Roller – Oval Track: Good Late Model cam w/388-406 on short track. |
| UPC Code |
36584670322 |
| Brand |
COMP CAMS |
| Type |
Camshafts |
| Condition |
New |
| Manufacturer Part Number (MPN) |
12-909-9 |
Description Camshaft – Oval Track – Mechanical Roller – Lift 0.630 / 0.630 in – Duration 296 / 304 – 104 LSA – 4200 / 7000 RPM – Small Block Chevy – Each Features
